324 MAPware-7000 Programming Manual
1010-1040, Rev. 02

System Setup Mode- these are a series of screens that provide information about the
current hardware (e.g. serial port settings) or to configure initial hardware settings such
as touchscreen calibration, enable beeper, screensaver timeout, etc. Press the System
Setup button to enter this mode. For more information on these screens, see System
Setup Mode.
Press the Exit button to leave the MODE SELECTION MENU. The HMC unit will reinitialize and
display the following screen:
HMC7000 HALT mode screen
This screen can be used to put the HMC7000 into HALT (suspended operation) mode. Normally,
when power is applied to the HMC7000, it initializes, runs a power-on diagnostics test, and then
attempts to execute the application (project).
This is called the Run mode.
There may be circumstances in which you wish the HMC7000 to not execute the application on
power-up until the plant floor operator presses a key on the HMC7000. This is called the Halt
mode.
The F1 function key toggles between the Run mode and Halt mode. The current operation
mode is specified in the first line below the screen divider:

RUN/HALT Switch position: RUN (HALT)
When this is set to RUN, the operator can press the F2 function key to cause the HMC7000 to
begin executing the installed application. Pressing the F1 function key changes the operation
mode to HALT.
