20 MAPware-7000 Programming Manual
1010-1040, Rev. 02
Click Refers to clicking the primary mouse button (usually the left mouse button) once.
Double-click Refers to quickly clicking the primary mouse button (usually the left mouse button)
twice.
Right-click Refers to clicking the secondary mouse button (usually the right mouse button) once.
Right-clicking usually opens shortcut menus.
The following table identifies symbols and margin icons.
Icon Meaning
► Identifies a procedure.
 Indicates a reference to additional information.
 Indicates an important note.
What You Need
The following items are needed to configure and operate your HMC7000.
Configuration Software MAPware-7000
I/O Expansion Modules All modules for the HMC7000 begin with a Maple P/N of HMC7;
visit our website for a complete listing of all available modules
Configuration Cable USB download cable with Type A and Type B connectors (Maple
P/N 7431-0116) or Serial download cable
Personal Computer User Provided
1
Power Cable 6030-0009 2-conductor 18 AWG, shielded, no connectors
24VDC Power Supply User Provided (or available from Maple Systems)
3 rd Party PLC (optional) User Provided
Controller Information Sheets Maple Systems provides Controller Information Sheets specific to
communicating to third party PLCs. Please locate the sheet that
corresponds to your PLC on our website.
Communication Cable Refer to our website ( www.maplesystems.com ) for a list of
available cables.
1 Computer requirements include a Pentium 800 MHz or higher processor, 256 MB RAM, 800
MB available Hard Disk Space, 1024x768 resolution color monitor, Keyboard and Mouse, USB
2.0 port for downloading project, one RS232 port for online simulation, Windows XP, Vista, or
Windows 7 operating system.
