MAPware-7000 Programming Manual 317
1010-1040, Rev. 02
35 High-speed
counter (HSC)
configuration
register (for
Channel 1- Slot
2) MW0400 Register
(2 bytes) Read/
Write HMC7030A-L Use to configure the HSC-
Channel 1 Slot 2
36 High-speed
counter (HSC)
Current value
(for Channel 1-
Slot 2) MW0401 Register
(2 bytes) Read/
Write HMC7030A-M,
HMC7035A-M,
HMC7057A-M Displays the current value
for HSC- Channel 1 Slot 2
37 High-speed
counter (HSC)
Preset value (for
Channel 1- Slot
2) MW0403 Register
(2 bytes) Read/
Write HMC7030A-M,
HMC7035A-M,
HMC7057A-M Use to set the preset value
for HSC- Channel 1 Slot 2
38 High-speed
counter (HSC)
configuration
register (for
Channel 2- Slot
2) MW0406 Register
(2 bytes) Read/
Write HMC7030A-M,
HMC7035A-M,
HMC7057A-M Use to configure the HSC-
Channel 2 Slot 2
39 High-speed
counter (HSC)
Current value
(for Channel 2-
Slot 2) MW0407 Register
(2 bytes) Read/
Write HMC7030A-M,
HMC7035A-M,
HMC7057A-M Displays the current value
for HSC- Channel 2 Slot 2
40 High-speed
counter (HSC)
Preset value (for
Channel 2- Slot
2) MW0409 Register
(2 bytes) Read/
Write HMC7030A-M,
HMC7035A-M,
HMC7057A-M Use to set the preset value
for HSC- Channel 2 Slot 2
41 High-speed
counter (HSC)
configuration
register (for
Channel 1- Slot
2) MW0500 Register
(2 bytes) Read/
Write HMC7030A-L Use to configure the HSC-
Channel 1 Slot 2
42 High-speed
counter (HSC)
Current value
(for Channel 1-
Slot 2) MW0501 Register
(2 bytes) Read/
Write HMC7030A-M,
HMC7035A-M,
HMC7057A-M Displays the current value
for HSC- Channel 1 Slot 2
