Page 75: 4device control (dctrl)
Lenze · 8400 motec · Reference manual · DMS 4.1 EN · 08/2013 · TD05
75
4
Device control (DCTRL)
4.2
Device state machine and device states
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
4.2.6
OperationEnabled
In the "OperationEnabled" state
• is the controller if the controller inhibit is deactivated and no trouble ("Trouble") and fault
("Fault") are existent.
• the operation is enabled and the motor follows the setpoint defined by the active application
(with sensorless vector control only after magnetisation has been completed).
Depending on certain conditions, a status change takes place based on the "OperationEnabled" de-
vice status.
Related topics:
LED status display
Display in status word 1 (
Bit 11
Bit 10
Bit 9
Bit 8
OperationEnabled
0
1
0
1
Change condition
Changeover to the device status
Control bit "EnableOperation" in control word wDriveControl = "0"
OR terminal RFR = LOW level (controller inhibit).
Control bit "SwitchOn" = "0".
Undervoltage in the DC bus.
(depending on
)
Error with error response "Trouble" occurs.
