11 Parameter reference
11.2 Parameter list | C00134
354 Lenze · 8400 motec · Reference manual · DMS 4.1 EN · 08/2013 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00134
C00136
Parameter | Name:
C00134 | Ramp rounding main setpoint
Data type: UNSIGNED_8
Index: 24441 d = 5F79 h
The L_NSet_1 FB: Configuration of the ramp rounding for the main setpoint
Selection list (Lenze setting printed in bold) Info
0 Off Ramp rounding deactivated
1 PT1 behaviour Ramp rounding with PT1 behaviour
• The corresponding S-ramp time must be set in
C00182 .
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00136 | Communication control words
Data type: UNSIGNED_16
Index: 24439 d = 5F77 h
 Communication
Display area (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded:
Bit 0 SwitchOn
Bit 1 IMP
Bit 2 SetQuickStop
Bit 3 EnableOperation
Bit 4 Reserved
Bit 5 Reserved
Bit 6 Reserved
Bit 7 ResetFault
Bit 8 SetHalt
Bit 9 reserved_1
Bit 10 reserved_2
Bit 11 LenzeSpecific_1
Bit 12 LenzeSpecific_2
Bit 13 LenzeSpecific_3
Bit 14 SetFail
Bit 15 LenzeSpecific_4
Subcodes Info
C00136/1 Network MCI/CAN control word
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
