Lenze · 8400 motec · Reference manual · DMS 4.1 EN · 08/2013 · TD05 357
11 Parameter reference
11.2 Parameter list | C00143
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00143
C00144
Parameter | Name:
C00143 | Selection of special functions
Data type: UNSIGNED_16
Index: 24432 d = 5F70 h
From version 04.01.00
Setting range (min. hex value | max. hex value) Lenze setting
0x0000 0xFFFF 0x0000 (decimal: 0)
Value is bit-coded: ( = bit set) Info
Bit 0  Brightness of the green LED Bit 1 | Bit 0: Brightness of the green LED
• 0 | 0 ≡ Maximum brightness
• 0 | 1 ≡ Reduced brightness - stage 1
• 1 | 0 ≡ Reduced brightness - stage 2
• 1 | 1 ≡ Minimum brightness
Use this function if the green light is too bright or
disturbing for your application.
• The green LED cannot be switched off completely in
order that the supply of the device with 400 V
remains visibly displayed from the outside.
• The setting only affects the green LED, not the red LED
(fault indication).
Bit 1  Brightness of the green LED
Bit 2  Reserved
Bit 3  Reserved
Bit 4  Reserved
Bit 5  Reserved
Bit 6  Reserved
Bit 7  Reserved
Bit 8  No IMP before DCB
From version 05.00.00
If this bit is set and the auto DCB threshold is ≤ 5 Hz, the
DC-injection braking is activated immediately if the
value falls below the threshold (without waiting time).

Automatic DC-injection braking (auto DCB)
Bit 9  Reserved
Bit 10  Reserved
Bit 11  Reserved
Bit 12  Reserved
Bit 13  Reserved
Bit 14  Reserved
Bit 15  Reserved
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C00144 | Switching frequency reduction (temp.)
Data type: UNSIGNED_8
Index: 24431 d = 5F6F h
Activation of the automatic switching frequency reduction if the temperature is too high
Selection list
(Lenze setting printed in bold) Info
0 Off Automatic switching frequency reduction deactivated
1 On Automatic switching frequency reduction activated
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
