Lenze · 8400 motec · Reference manual · DMS 4.1 EN · 08/2013 · TD05
203
7
Technology applications
7.2
TA "Actuating drive speed"
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Configuration parameters for analog setpoints:
Display parameter:
bRLQCw
)
: bTrue Activate clockwise rotation (fail-safe)
bRLQCcw
)
0: Not connected
Activate counter-clockwise rotation (fail-safe)
bSetSpeedCcw
)
:
bIn4 (DI4)
Change of direction of rotation
bJogSpeed1
)
:
bIn1 (DI1)
Selection of fixed setpoints (JOG setpoints)
bJogSpeed2
)
:
bIn2 (DI2)
bPIDEnableInfluenceRamp
)
: bTrue
: Activate ramp for influencing factor
bPIDIOff
)
0: Not connected
: Switch off I component
bPIDOff
)
0: Not connected
: Reset the entire PID controller
•
From version 04.00.00
bCInh
)
: bTrue
bFailReset
)
:
bCInh (RFR)
bSetQuickstop
)
0: Not connected
Enable quick stop (QSP)
bSetDCBrake
)
:
bIn3 (DI3)
Parameter
Selection of signal source
(Lenze setting)
for setpoint selection:
nMainSetValue_a
)
10:
nIn1_a
(Analog input 1)
Main setpoint
• 100 % ≡ reference speed (
)
nPIDSetValue_a
)
0: Not connected
: Sensor setpoint or process setpoint for
operating mode 2
nPIDVpAdapt_a
)
nPos100_a (100%)
: Adaptation of the gain Vp set in
percent
nPIDActValue_a
)
0: Not connected
: Actual speed value or actual sensor value
(actual process value)
nPIDInfluence_a
)
nPos100_a (100%)
: Limitation of the influencing factor in
percent
Parameter
Info
nIn_a
)
Input value of motor potentiometer
nNset_a
)
Input value of setpoint generator
nOut_a
)
Output value of setpoint generator
nSpeedSetValue_a
)
Speed setpoint for motor control
nSet_a
)
Sensor setpoint or process setpoint for operating mode 2
Parameter
Selection of signal source
(Lenze setting)
for control signal:
