Page 73: 4device control (dctrl)
Lenze · 8400 motec · Reference manual · DMS 4.1 EN · 08/2013 · TD05
73
4
Device control (DCTRL)
4.2
Device state machine and device states
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
4.2.4
ReadyToSwitchOn
In the "ReadyToSwitchOn" device state
• is the controller after the initialisation has been completed successfully.
• is the controller even after cancelling "
" or "
".
• is the controller if bit 0 ("SwitchOn") in the MCI/CAN control word is not set.
• Display parameter for MCI/CAN control word:
• Configuration parameter for MCI/CAN control word:
• I/O signalare evaluated.
• the monitoring modes are active.
• the controller can be parameterised.
• the application is basically executable.
• prevents in the Lenze setting the auto-start option " Inhibit at power-on" activated in
"
from changing to the "
" state.
LED status display
Display in status word 1 (
Bit 11
Bit 10
Bit 9
Bit 8
ReadyToSwitchOn
0
0
1
1
Danger!
If the "Inhibit at power-on" auto-start option has been deactivated in
, the "Read-
yToSwitchOn status switches directly to the "
" status after mains connec-
tion.
