6.3 User-defined terminal assignment
In order to individually adapt the preconfigured assignment of the input/output terminals to your
application, you can choose one of the following procedures:
A. In the »Engineer«:
• Change the terminal assignment on the Terminal assignment tab.
• Change the signal assignment on the Application Parameters tab, on the dialog level Over-
view  Signal flow.
B. In the »Engineer« or with the keypad:
• Change the parameters for signal configuration in the parameters list.

Tip!
First set a suitable Lenze configuration by selecting a corresponding control mode in
C00007 .
We recommend using the »Engineer« for the implementation of comprehensive user-de-
fined drive solutions.

Note!
If you change the preconfigured assignment of the digital and analog input/output ter-
minals, the terminal assignment will be a user-defined one. In C00007 , control mode "0:
Interconnection changed" will be shown.
If you select a different control mode in
C00007 , all configuration parameters ( C00620/
x , C00621/x , C00700/x and C00701/x ) are reset to the Lenze default setting for the se-
lected control mode. This also applies if the 8400 motec is parameterised via DIP switch-
es.
 Pre-assignment of the application ( 220)
