Lenze · 8400 motec · Reference manual · DMS 4.1 EN · 08/2013 · TD05 219
7 Technology applications
7.2 TA "Actuating drive speed"
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
7.2.4 Setting parameters (short overview)
Parameter Info Lenze setting
Value Unit
C00012 Accel. time - main setpoint 2.0 s
C00013 Decel. time - main setpoint 2.0 s
C00182 S-ramp time PT1 20.00 s
C00134 Ramp rounding - main setpoint 0: Off
C00019 Auto-DCB: Threshold 3 rpm
C00036 DCB: Current 50.0 %
C00039/1 Fixed setpoint 1 40.0 %
C00039/2 Fixed setpoint 2 60.0 %
C00039/3 Fixed setpoint 3 80.0 %
C00105 Decel. time - quick stop 5.0 s
C00106 Auto-DCB: Hold time 0.5 s
C00107 DCB: Hold time 999.0 s
C00222 L_PCTRL_1: Vp 1.0
C00223 L_PCTRL_1: Tn 400 ms
C00224 L_PCTRL_1: Kd 0.0
C00225 L_PCTRL_1: MaxLimit 199.9 %
C00226 L_PCTRL_1: MinLimit -199.9 %
C00227 L_PCTRL_1: Acceleration time 0.1 s
C00228 L_PCTRL_1: Deceleration time 0.1 s
C00231/1 L_PCTRL_1: Pos. maximum 199.9 %
C00231/2 L_PCTRL_1: Pos. minimum 0.0 %
C00231/3 L_PCTRL_1: Neg. minimum 0.0 %
C00231/4 L_PCTRL_1: Neg. maximum 199.9 %
C00233 L_PCTRL_1: Root function 0: Off
C00242 L_PCTRL_1: Operating mode 0: Off
C00243 L_PCTRL_1: Accel. time influence 5.0 s
C00244 L_PCTRL_1: Deceleration time influence 5.0 s
C00245 L_PCTRL_1: PID output value - %
C00246 L_PCTRL_1: nAct_a internal - %
C00800 L_MPot_1: Upper limit 100.0 %
C00801 L_MPot_1: Lower limit -100.0 %
C00802 L_MPot_1: Acceleration time 10.0 s
C00803 L_MPot_1: Deceleration time 10.0 s
C00804 L_MPot_1: Inactive fct. 0: Retain value
C00805 L_MPot_1: Init fct. 0: Load last value
C00806 L_MPot_1: Use 0: No
