4
Device control (DCTRL)
4.2
Device state machine and device states
74
Lenze · 8400 motec · Reference manual · DMS 4.1 EN · 08/2013 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
4.2.5
SwitchedOn
In the "SwitchedOn" device state
• is the controller if the user has inhibited the controller (and no error is pending).
• I/O signalare evaluated.
• the monitoring modes are active.
• the controller can be parameterised.
• the application is basically executable.
• it can be changed to the "
" state by deactivating the controller inhibit.
Tip!
provides a bit coded representation of all active sources/triggers of a controller in-
hibit.
Depending on certain conditions, a status change takes place based on the "SwitchedOn" device sta-
tus:
Related topics:
LED status display
Display in status word 1 (
Bit 11
Bit 10
Bit 9
Bit 8
SwitchedON
0
1
0
0
Change condition
Changeover to the device status
Control bit "EnableOperation" in control word wDriveControl = "1"
AND terminal RFR = HIGH level (controller enable)
Control bit "SwitchOn" = "0".
Motor parameter identification requested.
Undervoltage in the DC bus.
(depending on
)
Error with error response "Trouble" occurs.
