7.2.1
Basic signal flow
When you go to the Application parameters tab to the top dialog level Overview and click the Signal
flow button, you will get one dialog level down to the signal flow of the application (here displayed
with the preset control mode "Terminals 0"):
Configuration parameters for digital control signals:
Motor potentiometer (
Device control (
)
Setpoint generator (
)
Process controller (
All input and output interfaces of the application are described in the chapter entitled
Parameter
Selection of signal source
(Lenze setting)
for control signal:
bMPotUp
)
0: Not connected
: Increase speed setpoint
bMPotDown
)
0: Not connected
: Decrease speed setpoint
bMPotInAct
)
0: Not connected
: Activate inactive function
bMPotEnable
)
0: Not connected
: Activate motor potentiometer function
