Lenze · 8400 motec · Reference manual · DMS 4.1 EN · 08/2013 · TD05 403
11 Parameter reference
11.2 Parameter list | C00890
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00890
C00909
C00910
Parameter | Name:
C00890 | LP_Network_InOut: Inversion
Data type: UNSIGNED_16
Index: 23685 d = 5C85 h
From version 04.00.00
This parameter serves to invert the control/status bits of the MCI port blocks.
Setting range
(min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded: Info
Bit 0 Active Bit set = inversion active
... ...
Bit 15 Active
Subcodes Lenze setting Info
C00890/1 0x0000 LP_Network_In: Invert.Ctrl_B0..15
C00890/2 0x0000 LP_Network_Out: Invert.State_B0..15
C00890/3 0x0000 LP_Network_In: Invert. In2_B0..15
C00890/4 0x0000 LP_Network_Out: Invert.Out2_B0..15
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C00909 | Speed limitation
Data type: INTEGER_16
Index: 23666
d
= 5C72
h
Max. positive/negative speed for all motor control modes
Setting range
(min. value | unit | max. value)
0.0 % 175.0
Subcodes Lenze setting Info
C00909/1 120.0 % Max. pos. speed
C00909/2 120.0 % Max. neg. speed
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00910 | Frequency limitation
Data type: UNSIGNED_16
Index: 23665
d
= 5C71
h
Max. positive/negative output frequency for all motor control modes
Setting range
(min. value | unit | max. value)
0 Hz 300
Subcodes Lenze setting Info
C00910/1 300 Hz Max. pos. output frequency
C00910/2 300 Hz Max. neg. output frequency
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
