Lenze · 8400 motec · Reference manual · DMS 4.1 EN · 08/2013 · TD05 421
11 Parameter reference
11.2 Parameter list | C01913
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01913
Parameter | Name:
C01913 | Switch poti: Analog values
Data type: INTEGER_16
Index: 22662 d = 5886 h
Display of the values set via the setting elements P1 ... P3
Note:
• Settings made by DIP1, DIP2, P1, P2 and P3 must be activated with the DIP1/switch 1. The settings are accepted
anew every time the mains is switched on. As a consequence, interim changes of parameters may be
overwritten.
• Information on how to commission the 8400 motec via the DIP switches/potentiometers can be found in the
mounting instructions!
Display range (min. value | unit | max. value)
-199.99 % 199.99
Subcodes Info
C01913/1 Setpoint potentiometer f1 (LocalSetValue)
C01913/2 Setpoint switch f2 (fixed setpoint)
C00039/1 is overwritten:
• Setting 0 ≡ 0 %
• Setting 1 ≡ 11 %
• Setting 2 ≡ 22 %
• Setting 3 ≡ 33 %
• Setting 4 ≡ 44 %
• Setting 5 ≡ 55 %
• Setting 6 ≡ 66 %
• Setting 7 ≡ 77 %
• Setting 8 ≡ 88 %
• Setting 9 ≡ 100 %
C00012 and C00013 are overwritten:
• Setting 0 ≡ 0.1 s
• Setting 1 ≡ 0.5 s
• Setting 2 ≡ 1.0 s
• Setting 3 ≡ 2.0 s
• Setting 4 ≡ 5.0 s
• Setting 5 ≡ 10.0 s
• Setting 6 ≡ 20.0 s
• Setting 7 ≡ 30.0 s
• Setting 8 ≡ 60.0 s
• Setting 9 ≡ 120.0 s
C01913/3 Ramp switch t1 (acceleration/deceleration time)
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
