7 Technology applications
7.2 TA "Actuating drive speed"
224 Lenze · 8400 motec · Reference manual · DMS 4.1 EN · 08/2013 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Control mode 40 / 41 for control via network
Config.
parameter
Identifier Control mode
40: Network (MCI/CAN)
see chapter [7.2.5.4]
41: Network (AS-i)
see chapter [7.2.5.5]
C620/5 LS_DisFree : wDis1 (C481/1) - -
C620/6 LS_DisFree : wDis2 (C481/2) - -
C620/7 LS_DisFree : wDis3 (C481/3) - -
C620/8 LS_DisFree : wDis4 (C481/4) - -
C620/9 LS_DisFree_a : nDis1_a (C482/1) - -
C620/10 LS_DisFree_a : nDis2_a (C482/2) - -
C620/11 LS_DisFree_a : nDis3_a (C482/3) - -
C620/12 LS_DisFree_a : nDis4_a (C482/4) - -
C620/20 LP_Network_Out : MCI_wState/CAN1_wState wDeviceStateWord -
C620/21 LP_Network_Out : MCI_wOut2/CAN1_wOut2 nMotorSpeedAct_a -
C620/22 LP_Network_Out : MCI_wOut3/CAN1_wOut3 nMotorSpeedSet_a -
C620/23 LP_Network_Out : MCI_wOut4/CAN1_wOut4 - -
C620/24 LP_Network_Out : MCI_wOut5/CAN2_wOut1 - -
C620/25 LP_Network_Out : MCI_wOut6/CAN2_wOut2 - -
C620/26 LP_Network_Out : MCI_wOut7/CAN2_wOut3 - -
C620/27 LP_Network_Out : MCI_wOut8/CAN2_wOut4 - -
C621/1 LS_DigitalOutput : bRelay bDriveFail bDriveFail
C621/2 LS_DigitalOutput : bOut1 (DO1) bDriveReady bDriveReady
C621/7 LA_NCtrl: bStatusBit0 - -
C621/8 LA_NCtrl: bStatusBit2 bImaxActive bImaxActive
C621/9 LA_NCtrl: bStatusBit3 bSpeedSetReached bSpeedSetReached
C621/10 LA_NCtrl: bStatusBit4 bSpeedActEqSet bSpeedActEqSet
C621/11 LA_NCtrl: bStatusBit5 bNactCompare bNactCompare
C621/12 LA_NCtrl: bStatusBit14 bSpeedCcw bSpeedCcw
C621/13 LA_NCtrl: bStatusBit15 bDriveReady bDriveReady
C621/16 LS_DisFree_b : bDis1 (C480/Bit0) - -
C621/17 LS_DisFree_b : bDis2 (C480/Bit1) - -
C621/18 LS_DisFree_b : bDis3 (C480/Bit2) - -
C621/19 LS_DisFree_b : bDis4 (C480/Bit3) - -
C621/20 LS_DisFree_b : bDis5 (C480/Bit4) - -
C621/21 LS_DisFree_b : bDis6 (C480/Bit5) - -
C621/22 LS_DisFree_b : bDis7 (C480/Bit6) - -
C621/23 LS_DisFree_b : bDis8 (C480/Bit7) - -
C621/30 LP_Network_Out :
MCI_bState/CAN1_bState_B0
- TRUE
C621/31 LP_Network_Out :
MCI_bState/CAN1_bState_B1
- bDriveReady
C621/32...45 LP_Network_Out :
MCI_bState/CAN1_bState_B2 ... B15
- -
C621/46...61 LP_Network_Out :
MCI_bOut2/CAN1_bOut2_B0 ... B15
- -
C621/62...77 LP_Network_Out :
MCI_bOut5/CAN2_bOut1_B0 ... B15
- -
