11 Parameter reference
11.3 Selection list - analog signals
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
11.3 Selection list - analog signals
This selection list is relevant for the following
configuration parameters:
Parameter
C00620 System connection list: 16-bit
C00700 LA_NCtrl: Analog connection list
Selection list - analog signals
0 Not connected
Frequently used constants:
1 LS_ParFix: C_nPos100_a(100.0%)
2 LS_ParFix: C_nNeg100_a(-100.0%)
3 LS_ParFix: C_nPos199_9_a(199.9%)
4 LS_ParFix: C_nNeg199_9_a(-199.9%)
5 LS_ParFix: C_w65535
6 LS_ParFix: C_wDriveCtrl
Local DIP switch and potentiometer:
7 LS_Local: DIP S1-S2
(Bit 16 ... bit 8 = S1; bit 0 ... bit 7 = S2)
8 LS_Local: potentiometer P2 (speed)
9 LS_Local: potentiometer P3 (ramp)
Analog terminals :
10 LS_AnalogInput: AIn1_Out
11 LS_AnalogInput: AIn2_Out
Motor potentiometer L_MPot_1 :
12 L_MPot_1: nNSet_a
Setpoint generator L_NSet_1 :
13 LA_NCtrl: nSetSpeedValueEff_a
Digital terminals :
14 LS_DigitalInput: nFreqIn12_a
Potentiometer P1:
15 LS_Local: potentiometer P1 (continuous)
Free parameters ( C00471/1...4 ):
16 LS_ParFree: wC471_1
17 LS_ParFree: wC471_2
18 LS_ParFree: wC471_3
19 LS_ParFree: wC471_4
Free parameters ( C00472/1...4 ):
20 LS_ParFree_a: nC472_1_a
21 LS_ParFree_a: nC472_2_a
22 LS_ParFree_a: nC472_3_a
23 LS_ParFree_a: nC472_4_a
Data received via network (MCI/CAN):
30 LP_Network_In: MCI_wCtrl/CAN1_wCtrl
31 LP_Network_In: MCI_wIn2/CAN1_wIn2
32 LP_Network_In: MCI_wIn3/CAN1_wIn3
33 LP_Network_In: MCI_wIn4/CAN1_wIn4
34 LP_Network_In: MCI_wIn5/CAN2_wIn1
35 LP_Network_In: MCI_wIn6/CAN2_wIn2
36 LP_Network_In: MCI_wIn7/CAN2_wIn3
37 LP_Network_In: MCI_wIn8/CAN2_wIn4
Output signals of the TA "Actuating drive speed" :
50 LA_NCtrl: nMotorFreqAct_a
Scaling:
16384 ≡ 100 % reference speed ( C00011 )
51 LA_NCtrl: nMotorSpeedSet_a
Scaling:
16384 ≡ 100 % reference speed ( C00011 )
52 LA_NCtrl: nMotorSpeedAct_a
Scaling:
16384 ≡ 100 % reference speed ( C00011 )
53 LA_NCtrl: nMotor Voltage_a
Scaling: 16384 ≡ 1000 V
54 LA_NCtrl: nDCVoltage_a
Scaling: 16384 ≡ 1000 V
55 LA_NCtrl: nMotorCurrent_a
Scaling: 16384 ≡ 100 % I
max_mot
( C00022 )
56 LA_NCtrl: nMotorTorqueAct_a
Scaling: 16384 ≡ 100 % M
max
( C00057 )
57 LA_NCtrl: nHeatsinktemperature_a
Scaling: 0 ... 16384 ≡ 0 ... 80 °C, at sub-zero
temperatures, the value "0" is output.
58 LA_NCtrl: nOutputSpeedCtrl_a
Scaling: 16384 ≡ 100 % M
n
( C00097 )
60 LA_NCtrl: nPIDOut_a
61 LA_NCtrl: nPIDOut1_a
62 LA_NCtrl: nPIDOut2_a
63 LA_NCtrl: nPIDInfluenceOut_a
70 LA_NCtrl: wDeviceStateWord
71 LA_NCtrl: wDeviceAuxStateWord
72 LA_NCtrl: wDetermFailNoLow
73 LA_NCtrl: wDetermFailNoHigh
74 LA_NCtrl: wDetermFailNoShort
Output signals of "GeneralPurpose" functions :
80 LS_Convert_1: Out1
81 LS_Convert_1: Out2
82 LS_Convert_2: Out1
83 LS_Convert_2: Out2
84 LS_Convert_3: Out1
85 LS_Convert_3: Out2
150 LS_ParReadWrite_1: wOutHWord
151 LS_ParReadWrite_1: wOutLWord
160 L_Counter_1: wOut
Selection list - analog signals
