Lenze · 8400 motec · Reference manual · DMS 4.1 EN · 08/2013 · TD05 367
11 Parameter reference
11.2 Parameter list | C00224
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00224
C00225
C00226
C00227
C00228
Parameter | Name:
C00224 | L_PCTRL_1: Kd
Data type: UNSIGNED_16
Index: 24351 d = 5F1F h
The L_PCTRL_1 FB: Derivative-action coefficient Kd for the PID process controller
Setting range (min. value | unit | max. value) Lenze setting
0.0 5.0 0.0
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10
Parameter | Name:
C00225 | L_PCTRL_1: MaxLimit
Data type: INTEGER_16
Index: 24350 d = 5F1E h
The L_PCTRL_1 FB: Maximum output value of the PID process controller
Setting range (min. value | unit | max. value) Lenze setting
-199.9 % 199.9 199.9 %
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00226 | L_PCTRL_1: MinLimit
Data type: INTEGER_16
Index: 24349
d
= 5F1D
h
The L_PCTRL_1 FB: Minimum output value of the PID process controller
Setting range (min. value | unit | max. value) Lenze setting
-199.9 % 199.9 -199.9 %
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00227 | L_PCTRL_1: Acceleration time
Data type: UNSIGNED_32
Index: 24348
d
= 5F1C
h
The L_PCTRL_1 FB: Acceleration time for the output value of the PID process controller
Setting range (min. value | unit | max. value) Lenze setting
0.0 s 999.9 0.1 s
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1000
Parameter | Name:
C00228 | L_PCTRL_1: Deceleration time
Data type: UNSIGNED_32
Index: 24347 d = 5F1B h
The L_PCTRL_1 FB: Deceleration time for the output value of the PID process controller
Setting range (min. value | unit | max. value) Lenze setting
0.0 s 999.9 0.1 s
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1000
