Lenze · 8400 motec · Reference manual · DMS 4.1 EN · 08/2013 · TD05 391
11 Parameter reference
11.2 Parameter list | C00633
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00633
C00634
Parameter | Name:
C00633 | L_NSet_1: Min.SkipFrq.
Data type: INTEGER_16
Index: 23942 d = 5D86 h
Minimum limit values for the speed blocking zones
• Selection of the minimum limit values for the blocking zones in which the speed must not be constant.
Setting range (min. value | unit | max. value)
0.0 % 199.9
Subcodes Lenze setting Info
C00633/1 0.0 % L_NSet_1 : Blocking speed1 min
C00633/2 0.0 % L_NSet_1 : Blocking speed2 min
C00633/3 0.0 % L_NSet_1 : Blocking speed3 min
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00634 | L_NSet_1: wState
Data type: UNSIGNED_16
Index: 23941 d = 5D85 h
The L_NSet_1 FB: Bit coded status display
Display area (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded: Info
Bit 0 No blocking zone active "1" ≡ No blocking zone set for constant speeds
Bit 1 Blocking zone 1 active "1" ≡ Suppression of constant speed characteristics
within the limits of blocking zone 1
Bit 2 Blocking zone 2 active "1" ≡ Suppression of constant speed characteristics
within the limits of blocking zone 2
Bit 3 Blocking zone 3 active "1" ≡ Suppression of constant speed characteristics
within the limits of blocking zone 3
Bit 4 Jog in blocking zone "1" ≡ A ramp is used to keep the speed setpoint within a
speed blocking zone
Bit 5 MaxLimit active "1" ≡ Speed setpoint is at the maximum speed limit
Bit 6 MinLimit active "1" ≡ Speed setpoint is at the minimum speed limit
Bit 7 Reserved
Bit 8 Reserved
Bit 9 Reserved
Bit 10 Reserved
Bit 11 Reserved
Bit 12 Reserved
Bit 13 Reserved
Bit 14 Reserved
Bit 15 Reserved
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
