C01912
Parameter | Name:
C01912 | Function DIP switch S2
Data type: UNSIGNED_8
Index: 22663
d
= 5887
h
Bit coded display of the DIP2 switch setting
Note:
• Settings made by DIP1, DIP2, P1, P2 and P3 must be activated with the DIP1/switch 1. The settings are accepted
anew every time the mains is switched on. As a consequence, interim changes of parameters may be
overwritten.
• Information on how to commission the 8400 motec via the DIP switches/potentiometers can be found in the
mounting instructions!
Display area
(min. hex value | max. hex value)
0x00
0xFF
Value is bit-coded:
Info
Bit 0 DIP1: Freq. setting
DIP2 | DIP1: V/f base frequency (
) and reference
)
• 0 | 0 ≡ 50 Hz, 1500 rpm
• 0 | 1 ≡ 60 Hz, 1800 rpm
• 1 | 0 ≡ 87 Hz, 2610 rpm
• 1 | 1 ≡ 120 Hz, 3600 rpm
Bit 1 DIP2: Freq. setting
Bit 2 DIP3: Analog input: Config.
DIP4 | DIP3: Configuration of analog input (
• 0 | 0 ≡ 0 ... 10 V (no load resistor)
• 0 | 1 ≡ 0 ... 20 mA (load resistor is active)
• 1 | 0 ≡ 4 ... 20 mA (load resistor is active)
• 1 | 1 ≡ Configuration of EPM
Bit 3 DIP4: Analog input: Config.
Bit 4 DIP5: Control source
DIP7 | DIP6 | DIP5: Control mode (
• 0 | 0 | 0 ≡ Local mode
• The technology application is controlled via the
control elements at the 8400 motec.
• Detailed information on this control mode can be
found in the mounting instructions/hardware
manual.
• 0 | 0 | 1 ≡ Terminals 0
• 0 | 1 | 0 ≡ Terminals 2
• 0 | 1 | 1 ≡ Terminals 11
• 1 | 0 | 0 ≡ Terminals 16
• 1 | 1 | 1 ≡ Network (MCI/CAN)
• all other ≡ Configuration of EPM
Bit 5 DIP6: Control source
Bit 6 DIP7: Control source
Bit 7 DIP8: Reserved
Read access Write access CINH PLC STOP No transfer COM MOT
