11 Parameter reference
11.2 Parameter list | C00701
394 Lenze · 8400 motec · Reference manual · DMS 4.1 EN · 08/2013 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00701
Parameter | Name:
C00701 | LA_NCtrl: Digital connection list
Data type: UNSIGNED_16
Index: 23874 d = 5D42 h
Selection list
See
selection list - digital signals
Subcodes Lenze setting Info
C00701/1 0: Not connected LA_NCtrl : bCInh
C00701/2 10: LS_DigitalInput: bCInh LA_NCtrl : bFailReset
C00701/3 0: Not connected LA_NCtrl : bSetQuickstop
C00701/4 13: LS_DigitalInput: bIn3 LA_NCtrl : bSetDCBrake
C00701/5 14: LS_DigitalInput: bIn4 LA_NCtrl : bSetSpeedCcw
C00701/6 11: LS_DigitalInput: bIn1 LA_NCtrl : bJogSpeed1
C00701/7 12: LS_DigitalInput: bIn2 LA_NCtrl : bJogSpeed2
C00701/8 0: Not connected LA_NCtrl : bMPotUp
C00701/9 0: Not connected LA_NCtrl : bMPotDown
C00701/10 0: Not connected LA_NCtrl : bMPotInAct
C00701/11 0: Not connected LA_NCtrl : bMPotEnable
C00701/12 0: Not connected LA_NCtrl : bRFG_0
C00701/13 0: Not connected LA_NCtrl : bSetError1
C00701/14 0: Not connected LA_NCtrl : bSetError2
C00701/15 1: LS_ParFix: bTrue LA_NCtrl : bPIDInfluenceRamp
C00701/16 0: Not connected LA_NCtrl : bPIDIOff
C00701/17 1: LS_ParFix: bTrue LA_NCtrl : bRLQCw
C00701/18 0: Not connected LA_NCtrl : bRLQCcw
C00701/19 15: LS_DigitalInput: bIn5 LA_NCtrl : bBrkRelease
C00701/20 0: Not connected L_Counter_1 : bClkUp
C00701/21 0: Not connected L_Counter_1 : bClkDown
C00701/22 0: Not connected L_Counter_1 : bLoad
C00701/23 0: Not connected L_DigitalDelay_1 : bIn
C00701/24 0: Not connected L_DigitalDelay_2 : bIn
C00701/25 0: Not connected LS_WriteParamList : bExecute
C00701/26 0: Not connected LS_WriteParamList : bSelectWriteValue_1
C00701/27 0: Not connected L_FreqIn12: bEncCntReset
C00701/28 0: Not connected L_DigitalLogic_1 : bIn1
C00701/29 0: Not connected L_DigitalLogic_1 : bIn2
C00701/30 0: Not connected L_DigitalLogic_2 : bIn1
C00701/31 0: Not connected L_DigitalLogic_2 : bIn2
C00701/32 0: Not connected LS_ParReadWrite_1 : bExecute
C00701/33 0: Not connected LS_ParReadWrite_1 : bReadWrite
C00701/34 0: Not connected LA_NCtrl : bPIDInAct
C00701/35 0: Not connected LA_NCtrl : bPIDOff
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
