Lenze · 8400 motec · Reference manual · DMS 4.1 EN · 08/2013 · TD05 411
11 Parameter reference
11.2 Parameter list | C01083
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01083
C01084
C01085
C01086
Parameter | Name:
C01083 | LS_WriteParamList: FailState
Data type: UNSIGNED_16
Index: 23492 d = 5BC4 h
Parameter change-over : Error status:
• 0 = no error
• 33803 | 0x840B = invalid data type (e.g. STRING)
• 33804 | 0x840C = limit violation
• 33806 | 0x840E = invalid code
• 33813 | 0x8415 = no element of the selection list
• 33815 | 0x8417 = writing of the parameter not permitted
• 33816 | 0x8418 = writing of the parameter only permitted if controller is inhibited
• 33829 | 0x8425 = invalid subcode
• 33865 | 0x8449 = no parameter with subcodes
Display range (min. value | unit | max. value)
0 34000
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01084 | LS_WriteParamList: Error line
Data type: UNSIGNED_8
Index: 23491 d = 5BC3 h
Parameter change-over : Display of the number of list entry where the error occurred (in connection with the value
set selected via bSelectWriteValue_1 and bSelectWriteValue_2).
Display range
(min. value | unit | max. value)
0 16
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01085 | LS_WriteParamList: Index
Data type: INTEGER_32
Index: 23490
d
= 5BC2
h
Parameter change-over : Parameter for entry 1 ... 16
Setting range (min. value | unit | max. value)
0.000 16000.000
Subcodes Lenze setting Info
C01085/1 0.000 Parameter for entries 1 ... 16
• Format: .
• Examples: "12.000" = C00012; "26.001" = C00026/1
C01085/...
C01085/16
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1000
Parameter | Name:
C01086 | LS_WriteParamList: WriteValue_1
Data type: INTEGER_32
Index: 23489 d = 5BC1 h
Parameter change-over : Parameter values - value set 1
Setting range (min. value | unit | max. value)
-2147483647 2147483647
Subcodes Lenze setting Info
C01086/1 0 Parameter values - value set 1
• Parameter values for the parameters defined in
C01085 /1 ... 16.
C01086/...
C01086/16
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
