Lenze · 8400 motec · Reference manual · DMS 4.1 EN · 08/2013 · TD05 453
12 Function library
12.3 L_PCTRL_1
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00242 Operating mode
• Lenze setting: "0: Off"
0 Off The input setpoint nNSet_a is output
without any changes at the output
nOut_a.
1 nNSet + nNSet_PID nNSet_a and nAct_a are used as PID
input values. The arriving nNSet_a is
additively linked to the value output
by the PID element.
2 nSet_PID nSet_a and nAct_a are used as PID
input values. The input nNSet_a is
not considered.
3 nNSet_PID nNSet_a and nAct_a are used as PID
input values. The input nSet_a is not
considered.
4 nNSet + nSet_PID
(from version 04.00.00)
nSet_a and nAct_a are used as PID
input values. The arriving nNSet_a
setpoint is additively linked to the
value output by the PID element.
5 nNSet || nSet_PID
(from version 04.00.00)
nSet_a and nAct_a are used as PID
input values. The setpoint nNSet_a is
output at the output nOut_a . The
PID output value is output at the
output nPIDOut_a.
C00243 0.0 s 999.9 Influence acceleration time
• Acceleration time T
ir
for the
influencing factor.
• Lenze setting: 5.0 s
C00244 0.0 s 999.9 Influence deceleration time
• Deceleration time T
if
for the
influencing factor.
• Lenze setting: 5.0 s
C00245 -199.9 % +199.9 Display of PID output value
nPIDOut_a
C00246
(from version 04.00.00)
-199.99 % +199.99 Display of the internal PID input
value nAct_a
Parameter Possible settings Info
