Lenze · 8400 motec · Reference manual · DMS 4.1 EN · 08/2013 · TD05 425
11 Parameter reference
11.2 Parameter list | C02607
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02607
C02610
Parameter | Name:
C02607 | Holding brake: Status
Data type: UNSIGNED_16
Index: 21968 d = 55D0 h
Switching status of the holding brake control
 Holding brake control
Display area (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded: Info
Bit 0 Brake applied Holding brake is completely applied
Bit 1 Brake released Holding brake is completely released
Bit 2 Feedforward control active Feedforward control for holding of the load via the motor
is active before the holding brake releases.
Bit 3 Closing active The brake closing time ( C02589/1 ) expires
Bit 4 Forced release active In case of automatic operation of the holding brake
control, the brake is directly released via the MCK input
bMBrakeRelease = TRUE
Bit 5 Release active The brake release time ( C02589/2 ) expires
Bit 6 Setpoint synchronisation active A speed setpoint at the MCK is approached along a
defined ramp after brake release
Bit 7 Brake control fault Motor phase error detected before brake is released. For
configuration of monitoring see C00597 .
Bit 8 Reserved
Bit 9 Reserved
Bit 10 Reserved
Bit 11 Reserved
Bit 12 Reserved
Bit 13 Reserved
Bit 14 Reserved
Bit 15 Reserved
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C02610 | MCK: Accel./decel. times
Data type: UNSIGNED_32
Index: 21965 d = 55CD h
From version 02.00.00
Ramp times for speed setpoint synchronisation
Setting range
(min. value | unit | max. value)
0.0 s 999.9
Subcodes Lenze setting Info
C02610/1 2.0 s Holding brake: ramp time synchr.
• Ramp time for the synchronisation process to
setpoint speed after the brake opening time has
elapsed
 Holding brake control
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1000
