6 I/O terminals
6.3 User-defined terminal assignment
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Configuration parameters for the digital output terminals
The subcodes of
C00621 can be used to change the preconfigured terminal assignment of the dig-
ital terminals:
Other subcodes (not shown here) allow the configuration of input signals of different system blocks
and port blocks.
Configuration parameters for the inputs of the application
The following parameters can be used to change the preconfigured assignment of the application
inputs:
Parameter Info Lenze setting
Value Unit
C00621/1 LS_DigitalOutput:bRelay 1001: LA_nCtrl_bDriveFail
C00621/2 LS_DigitalOutput:bOut1 1000: LA_nCtrl_bDriveReady
Parameter Info Lenze setting
C00700/1 LA_NCtrl : nMainSetValue_a 10: AIn1_Out
C00700/2 LA_NCtrl : nTorqueMotLim_a 22: nPar3_a
C00700/3 LA_NCtrl : nTorqueGenLim_a 22: nPar3_a
C00700/4 Key-operated switch: Max. speed 15: Local potentiometer P1
C00700/5 LA_NCtrl :Network(MCI/CAN)_wDriveControl 6: C_wDriveCtrl
C00700/6 LA_NCtrl : nPIDVpAdapt_a 1: C_nPos100_a(100.0%)
C00700/7 LA_NCtrl : nPIDActValue_a 0: Not connected
C00700/8 LA_NCtrl : nPIDInfluence_a 1: C_nPos100_a(100.0%)
C00700/9 LA_NCtrl : nPIDSetValue_a 0: Not connected
C00700/10 Reserved 0: Not connected
C00700/11 L_Counter_1 : wLdVal 0: Not connected
C00700/12 L_Counter_1 : wCmpVal 0: Not connected
C00700/13 L_Compare_1 : nIn1_a 0: Not connected
C00700/14 L_Compare_1 : nIn2_a 0: Not connected
C00700/15 LS_ParReadWrite_1 : wParIndex 0: Not connected
C00700/16 LS_ParReadWrite_1 : wParSubindex 0: Not connected
C00700/17 LS_ParReadWrite_1 : wInHWord 0: Not connected
C00700/18 LS_ParReadWrite_1 : wInLWord 0: Not connected
C00701/1 LA_NCtrl : bCInh 0: Not connected
C00701/2 LA_NCtrl : bFailReset 10: DigIn_CInh
C00701/3 LA_NCtrl : bSetQuickstop 0: Not connected
C00701/4 LA_NCtrl : bSetDCBrake 13: DigIn_bIn3
C00701/5 LA_NCtrl : bSetSpeedCcw 14: DigIn_bIn4
C00701/6 LA_NCtrl : bJogSpeed1 11: DigIn_bIn1
C00701/7 LA_NCtrl : bJogSpeed2 12: DigIn_bIn2
C00701/8 LA_NCtrl : bMPotUp 0: Not connected
C00701/9 LA_NCtrl : bMPotDown 0: Not connected
C00701/10 LA_NCtrl : bMPotInAct 0: Not connected
C00701/11 LA_NCtrl : bMPotEnable 0: Not connected
C00701/12 LA_NCtrl : bRFG_0 0: Not connected
C00701/13 LA_NCtrl : bSetError1 0: Not connected
