11.4
Selection list - digital signals
This selection list is relevant for the following
configuration parameters:
Parameter
System connection list: Bool
LA_NCtrl: Digital connection list
Selection list - digital signals
0 Not connected
Frequently used constants:
1 LS_ParFix: bTrue
:
10 LS_DigitalInput: CInh
11 LS_DigitalInput: bIn1
12 LS_DigitalInput: bIn2
13 LS_DigitalInput: bIn3
14 LS_DigitalInput: bIn4
15 LS_DigitalInput: bIn5
16 LS_DigitalInput: bIn6
17 LS_DigitalInput: bIn7
18 LS_DigitalInput: bIn8
Free parameters (
):
20 LS_ParFree_b: bC470_1
21 LS_ParFree_b: bC470_2
22 LS_ParFree_b: bC470_3
23 LS_ParFree_b: bC470_4
24 LS_ParFree_b: bC470_5
25 LS_ParFree_b: bC470_6
26 LS_ParFree_b: bC470_7
27 LS_ParFree_b: bC470_8
28 LS_ParFree_b: bC470_9
29 LS_ParFree_b: bC470_10
30 LS_ParFree_b: bC470_11
31 LS_ParFree_b: bC470_12
32 LS_ParFree_b: bC470_13
33 LS_ParFree_b: bC470_14
34 LS_ParFree_b: bC470_15
35 LS_ParFree_b: bC470_16
Output signals of the
:
50 LA_NCtrl: bDriveFail
51 LA_NCtrl: bDriveReady
52 LA_NCtrl: bCInhActive
53 LA_NCtrl: bQSPIsActive
54 LA_NCtrl: bSafeTorqueOff
55 LA_NCtrl: bSafetyIsActive
56 LA_NCtrl: bOperationEnable
57 LA_NCtrl: bRemoteControlActive
58 LA_NCtrl: bDriveWarning
60 LA_NCtrl: bSpeedCcw
61 LA_NCtrl: bActSpeedEqZero
62 LA_NCtrl: bSpeedSetReached
63 LA_NCtrl: bSpeedActEqSet
64 LA_NCtrl: bNActCompare
65 LA_NCtrl: bImaxActive
66 LA_NCtrl: bHeatSinkWarning
67 LA_NCtrl: bOVDetected
68 LA_NCtrl: bDCBrakeOn
69 LA_NCtrl: bFlyingSyncActive
70 LS_AnalogInput: bCurrentErrorIn1
71 LA_NCtrl: bPIDActEqSet
80 LA_NCtrl: bUVDetected
81 LA_NCtrl: bIxtOverload
82 LA_NCtrl: bI2xtOverload
83 LA_NCtrl: bMMax
84 LA_NCtrl: bNMaxFault
85 LA_NCtrl: bMotorPTCFault
87 LA_NCtrl: bAutoGSBIsActive
88 LA_NCtrl: bClampActive
89 LA_NCtrl: bIMPIsActive
Data received via network (MCI/CAN):
100 LP_Network_In:MCI_bCtrl_B0/CAN1_bCtrl_B0
101 LP_Network_In:MCI_bCtrl_B1/CAN1_bCtrl_B1
102 LP_Network_In:MCI_bCtrl_B2/CAN1_bCtrl_B2
103 LP_Network_In:MCI_bCtrl_B3/CAN1_bCtrl_B3
104 LP_Network_In:MCI_bCtrl_B4/CAN1_bCtrl_B4
105 LP_Network_In:MCI_bCtrl_B5/CAN1_bCtrl_B5
106 LP_Network_In:MCI_bCtrl_B6/CAN1_bCtrl_B6
107 LP_Network_In:MCI_bCtrl_B7/CAN1_bCtrl_B7
108 LP_Network_In:MCI_bCtrl_B8/CAN1_bCtrl_B8
109 LP_Network_In:MCI_bCtrl_B9/CAN1_bCtrl_B9
110 LP_Network_In:MCI_bCtrl_B10/CAN1_bCtrl_B10
111 LP_Network_In:MCI_bCtrl_B11/CAN1_bCtrl_B11
112 LP_Network_In:MCI_bCtrl_B12/CAN1_bCtrl_B12
113 LP_Network_In:MCI_bCtrl_B13/CAN1_bCtrl_B13
114 LP_Network_In:MCI_bCtrl_B14/CAN1_bCtrl_B14
115 LP_Network_In:MCI_bCtrl_B15/CAN1_bCtrl_B15
120 LP_Network_In:MCI_bIn2_B0/CAN1_bIn2_B0
121 LP_Network_In:MCI_bIn2_B1/CAN1_bIn2_B1
122 LP_Network_In:MCI_bIn2_B2/CAN1_bIn2_B2
123 LP_Network_In:MCI_bIn2_B3/CAN1_bIn2_B3
124 LP_Network_In:MCI_bIn2_B4/CAN1_bIn2_B4
125 LP_Network_In:MCI_bIn2_B5/CAN1_bIn2_B5
126 LP_Network_In:MCI_bIn2_B6/CAN1_bIn2_B6
127 LP_Network_In:MCI_bIn2_B7/CAN1_bIn2_B7
128 LP_Network_In:MCI_bIn2_B8/CAN1_bIn2_B8
129 LP_Network_In:MCI_bIn2_B9/CAN1_bIn2_B9
130 LP_Network_In:MCI_bIn2_B10/CAN1_bIn2_B10
131 LP_Network_In:MCI_bIn2_B11/CAN1_bIn2_B11
132 LP_Network_In:MCI_bIn2_B12/CAN1_bIn2_B12
133 LP_Network_In:MCI_bIn2_B13/CAN1_bIn2_B13
134 LP_Network_In:MCI_bIn2_B14/CAN1_bIn2_B14
Selection list - digital signals
