11 Parameter reference
11.2 Parameter list | C00680
392 Lenze · 8400 motec · Reference manual · DMS 4.1 EN · 08/2013 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00680
C00681
C00682
Parameter | Name:
C00680 | L_Compare_1: Fct.
Data type: UNSIGNED_8
Index: 23895 d = 5D57 h
The L_Compare_1 FB: Comparison operation
• If the statement of the selected comparison operation is true, the binary bOut output will be set to TRUE.
Selection list (Lenze setting printed in bold)
1 In1 = In2
2 In1 > In2
3 In1 < In2
4 |In1| = |In2|
5 |In1| > |In2|
6 |In1| < |In2|
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00681 | L_Compare_1: Hysteresis
Data type: INTEGER_16
Index: 23894 d = 5D56 h
The L_Compare_1 FB: Hysteresis for the comparison function selected in C00680
Setting range (min. value | unit | max. value) Lenze setting
0.0 % 100.0 0.5 %
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00682 | L_Compare_1: Window
Data type: INTEGER_16
Index: 23893
d
= 5D55
h
The L_Compare_1 FB: Window for the comparison function selected in C00680
Setting range (min. value | unit | max. value) Lenze setting
0.0 % 100.0 2.0 %
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
