Lenze · 8400 motec · Reference manual · DMS 4.1 EN · 08/2013 · TD05
63
4
Device control (DCTRL)
4.1
Device commands (C00002/x)
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
4.1.2
Load parameter set 1
= "1: On / start" device command reloads all parameters from the memory module to
the controller.
• The DIP switches are not used anymore to overwrite data.
• Can only be executed if the controller is inhibited; otherwise, the feedback
= "6: No
access - controller inhibit" will be returned.
• All parameter changes made since the last saving of the parameter set will get lost!
• This device command has an effect on the settings of the parameters of the operating system,
application and module.
How to load the parameter set 1 from the memory module:
1. If the controller is enabled, it must be inhibited, e.g. by executing the "Enable/Inhibit con-
troller" device command (
= "0: Off / ready").
2. Execute the "Load parameter set 1" device command:
= "1: On / start"
The load process may take a couple of seconds. After the device command has been called
, a dynamic status information ("Work in progress" "Off / Ready") is re-
turned.
Note!
• When the device is switched on, all parameters are automatically loaded from the
memory module to the main memory of the controller.
• When the DIP switches are active (DIP switches S1\1 = "ON"), the controller oper-
ates with the settings made via the DIP switches and displays them in the corre-
sponding codes.
• The controller has a parameter set.
• Up to 16 selectable parameters can be switched over via the basic
function.
