Lenze · 8400 motec · Reference manual · DMS 4.1 EN · 08/2013 · TD05 351
11 Parameter reference
11.2 Parameter list | C00114
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00114
C00115
Parameter | Name:
C00114 | DIx inversion
Data type: UNSIGNED_16
Index: 24461 d = 5F8D h
The polarity of each digital input of the device can be inverted via this bit field.
 Digital terminals
Setting range (min. hex value | max. hex value) Lenze setting
0x0000 0xFFFF 0x8000 (decimal: 32768)
Value is bit-coded: ( = bit set) Info
Bit 0  DI1 inverted Inversion of digital input 1
Bit 1  DI2 inverted Inversion of digital input 2
Bit 2  DI3 inverted Inversion of digital input 3
Bit 3  DI4 inverted Inversion of digital input 4
Bit 4  DI5 inverted Inversion of digital input 5
Bit 5  DI6 inverted Inversion of digital input 6
Bit 6  DI7 inverted Inversion of digital input 7
Bit 7  DI8 inverted Inversion of digital input 8
Bit 8  Reserved
Bit 9  Reserved
Bit 10  Reserved
Bit 11  Reserved
Bit 12  Reserved
Bit 13  Reserved
Bit 14  Reserved
Bit 15  RFR inverted
Inversion of digital input RFR (controller enable)
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C00115 | DI1| DI2: Function
Data type: UNSIGNED_8
Index: 24460 d = 5F8C h
From version 02.00.00
Function assignment of the digital terminals DI1 and DI2
 Digital terminals : Function assignment
Selection list Info
0 DI1=In1 | DI2=In2 DI1 = digital input
DI2 = digital input
1 DI1=FreqIn12 | DI2=In2 DI1 = 1-track frequency input
DI2 = digital input
2 (DI1/DI2)=FreqIn12 (2-track) DI1 and DI2 = 2-track frequency input
3 (DI1/DI2=+-)=FreqIn12 DI1 = 1-track frequency input
DI2 = specification of direction
Subcodes Lenze setting Info
C00115/1 0: DI1=In1 | DI2=In2 Function assignment of DI1 and DI2
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
