Physical
A parameter used by SCF and the guided procedures that allows SANMAN
to select an appropriate switch configuration block (SCB) from the M6770CL
switch configuration library. The selected SCB is subsequently loaded on the
specified switch. The configuration tag determines the position of the cluster
switch in the topology and the ServerNet node numbers supported by the
cluster switch.
Values
Example: Max 24 nodes, nodes 1-8
Configuration Tag
A unique, read-only number stored in nonvolatile memory (SEEPROM) on a
ServerNet II switch. The Globally Unique ID can be used programmatically
to identify the switch. GUID
Whether the switch is configured for operation on the X fabric or the Y fabric.
Values: X, Y, or Clear Fabric Setting
Verification that the switch is installed and responding.
Values: Present, Absent, Unknown Presence
The version of the configuration file currently loaded on the switch.
Example: 1_5 Configuration Version
The version of the firmware currently loaded on the switch.
Example: 3_0_23 Firmware Version
Actions
None.
ServerNet Cluster
A ServerNet cluster is a collection of NonStop servers connected together that function as a single
processing unit. Servers within a ServerNet cluster pass information to each other using the ServerNet
protocol.
Location in OSM tree: Located at the top level.
See also Managing a ServerNet Cluster .
Attributes
ServerNet Cluster
Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK.
Values
Service State
Logical
The software version of the SNETMON process ($ZZSCL).
Example: SCL - T0294G08 - (11AUG03) - (07JUL03) - (AAL) SNETMON Version
The number of ServerNet nodes that are possible with the current topology
of the cluster. Maximum Number of Nodes
The number of ServerNet nodes that are currently members of this cluster. Current Number of Nodes
