Test Basic Online

Runs an online test to determine if the CLIP is functional, and checks that both the access paths are
available.

Test Full Path Access

Tests two-way access to the communications line interface processor (CLIP) using both the primary
and alternate addresses.

Test Primary Path Access

Tests two-way access to the communications line interface processor (CLIP) using the primary
address

Test Verify

Runs the power-on self-test for the CLIP. The FAULT LED on the CLIP flashes during the test. If the
test passes, the FAULT LED goes off. If the test fails, the FAULT LED remains on continuously.

SWAN Collection

When one or more

SWAN or SWAN 2

concentrator CRUs are connected to a system, a SWAN

Collection object appears in both the tree pane and the overview pane of the OSM Service
Connection. In both panes, this object displays an alarm or yellow icon if alarms or degraded
conditions exist on any of the individual SWAN CRUs contained within. You can expand the
SWAN Collection icon in the tree pane (but not in the overview pane) to select and monitor
individual SWAN CRUs and their subcomponents.

Location in OSM Tree: Under System

Example: SWAN Collection

Attributes

None.

Actions

None.

SWAN FAN

Each SWAN 2 CRU has two customer-replaceable fan subcomponents.

Location in OSM Tree: System > SWAN Collection > SWAN > Fan

Example: Fan $ZZWAN.#SWAN2.FAN1

Attributes

Fan $ZZWAN

Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK.

Values

Service State

Logical

The state of the component as known to the operating system on the server.

Values

Device State

228 System Resources
