Valid only for NonStop BladeSystems, this attribute maps the Logical Processor
to the Processor Blade it represents.

Processor Blade

Indicates whether the processor freeze state is enabled or disabled.

Processor Freeze State

The state of the Logical Processor as seen by the Maintenance Entity (ME) of
the associated ServerNet Switch Board.

Values

Processor State (from ME)

The NonStop server type.

Values

Example: NSE-A

Processor Type

Indicates whether the current processor configuration includes one (Simplex),
two (Duplex), or three (Triplex) Blade Elements.

NOTE:

Valid for NS16000 series and NS14000 series servers only.

Redundancy State

Total amount of memory on the processor.

NOTE:

Displayed only for (J-series) NonStop BladeSystems; not applicable

for NonStop NS-series servers.

Total Memory Size

The state of the Internal ServerNet X Fabric.
Values: Up, Disabled

X Fabric ServerNet State

The state of the Internal ServerNet Y Fabric.
Values: Up, Disabled

Y Fabric ServerNet State

Physical

NOTE:

Displayed only for Integrity NonStop NS1000, NS1200, NS2000 series, NS2100,

NS2200 series, NS2300, NS2400 series, NS5000, and NS3000AC servers.

The part number of the component that was assigned in manufacturing. Use
part numbers for identifying and ordering parts.

NOTE:

Not displayed for NS2100, NS2200 series, NS2300, or NS2400

series servers.

Part Number

A unique serial number that identifies the component. Track IDs are used for
tracking components.

Track ID

X Fabric Connection

The port on the Processor Switch to which the Logical Processor is connected
on the X Fabric.

Port Name

Y Fabric Connection

The port on the Processor Switch to which the Logical Processor is connected
on the Y Fabric.

Port Name

Actions

Disable Processor Freeze

Turns the Freeze Enable flag on this processor off. A freeze-disabled processor is unaffected when
any other processor halts or the (Low-Level Link) system-level Freeze action is performed.

172

System Resources
