Y Fabric Connection #2
Identifies the Y2 port used for BladeCluster connectivity. Port Name
X Fabric Connection #1
Identifies the X1 port used for BladeCluster connectivity. Port Name
X Fabric Connection #2
Identifies the X2 port used for BladeCluster connectivity. Port Name
Actions
Generate ServerNet Statistics
Generates an event containing the ServerNet statistics for the node.
X Fabric Responsive Test
Issues a responsive test to test the connectivity between this node and other nodes on the X fabric.
Y Fabric Responsive Test
Issues a responsive test to test the connectivity between this node and other nodes on the Y fabric.
Remote 6770 Switch
The nodes connected directly to one switch see the other switches as remote switches. Although
local and remote switches are the same from a hardware standpoint, less information and no
actions are available for the remote switch. To perform actions or get additional information on a
remote switch, establish a service connection from one of the nodes that connects directly to that
switch.
Location in OSM tree: External ServerNet Fabric > Remote Switch
The last part of the switch name indicates the fabric and position of the switch in the topology.
Example: Remote Switch $ZZSMN.X2
Attributes
Remote Switch
Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK.
Values
Service State
274 Cluster Resources
