Configuration

A parameter used by SCF and the guided procedures that allows SANMAN
to select an appropriate switch configuration block (SCB) from the M6770CL
switch configuration library. The selected SCB is subsequently loaded on the
specified switch. The configuration tag determines the position of the cluster
switch in the topology and the ServerNet node numbers supported by the
cluster switch.

Values

Example: Max 24 nodes, nodes 17-24

Configuration Tag

The version of the configuration currently loaded on the switch. The attribute
value includes the VPROC string with the configuration version in parentheses.
You can also obtain this value from SCF.
Example: T0569G06^02Jul01^CL4^AAE (2_5)

Version

The full path name of the default configuration file M6770CL.

Default File Name

A number that indicates the position that the switch occupies in a network
topology. The Position ID is a component of the switch name. For example,
the switch name X3 indicates that the switch serves the external ServerNet
X fabric and occupies position 3 in the topology.

Position ID

The version of firmware in the default configuration file M6770CL.

Default File Version

The differences, if any, between the current and default configuration versions.

Values

Compare State

Actions

Blink LED Off

Turns off the blinking of the LED.

SCF Equivalent: SCF ALTER SWITCH $ZZSMN, NEAREST { X | Y}, BLINK NONE

Blink LED On

Causes the LED to start blinking.

SCF Equivalent: SCF ALTER SWITCH $ZZSMN, NEAREST { X | Y}, BLINK ALL

Configuration Update

This action updates the configuration for the ServerNet II switch component of the 6770 switch
module. For more information, see

Updating Cluster Switches

.

NOTE:

If you are updating both firmware and configuration on the same cluster switch, you

should always update the firmware first. In some circumstances, updating both firmware and
configuration is not necessary. For more information, see the ServerNet Cluster Manual.

Optional Parameter: File name of the configuration file.

Firmware Update

Updates the firmware on the ServerNet II switch component of the 6770 switch module. For more
information, see

Updating Cluster Switches

.

Optional Parameter: File name of the firmware file.

280 Cluster Resources
