NOTE: Displayed only for (J-series) NonStop BladeSystems; not applicable for NonStop NS-series
servers.
ServerNet Interface Card (CLIM)
A subcomponent of the CLIM .
Location in OSM Tree: System > CLIMs > CLIM > ServerNet Interface Card
Attributes
ServerNet Interface Card
Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK.
Values
Service State
Physical
The product name of the ServerNet interface card. Model
Actions
Replace
Launches a documented service procedure to replace a ServerNet interface card in a CLIM.
ServerNet PIC
A processor switch plug-in card (PIC) used for internal ServerNet connections. ServerNet PICs are
installed in slots 2 through 13 of the processor switch. Each PIC contains two to four
ports .
Depending on the needs of your system, some slots might not have PICs installed.
• Slot 2 contains a cluster PIC if your system is part of a ServerNet cluster.
• Slot 3 contains a crosslink PIC that connects the X-fabric and Y-fabric processor switches.
• Slots 4 through 9 contain I/O PICs that connect to an IOAM enclosure or Nonstop S-series
IOMF2 enclosures.
• Slots 10 through 13 contain processor PICs that connect to the processors.
Attributes
Physical
A code that identifies the generation of the component. Hardware revision
codes are used for tracking components. Hardware Revision
Indicates whether or not the power supply’s amber LED is lit. This state is
determined by the
Set LED State action.
Value: On or Off
LED State
The part number of the component that was assigned in manufacturing. Use
part numbers for identifying and ordering parts. Part Number
Indicates whether the component is powered on. Values Power State
ServerNet Interface Card (CLIM) 211
