1.
In the tree pane of the OSM management window, expand the ServerNet Cluster resource
and navigate to the Switch component of the Switch Module.
2.
Right-click the Switch component and select Attributes. In the Configuration section, check the
value of the Compare State attribute. If it is Down-rev, continue with this procedure.
3.
Right-click the Switch component and select Actions The Actions dialog box appears.
4.
In the Available Actions drop-down list, select the Configuration Update action and click
Perform action. Follow the screen prompts and monitor the status of the action.
5.
When you are prompted to perform a Hard Reset action:
•
Click Yes to perform the reset now. ServerNet traffic through the switch is temporarily
disrupted.
•
Click No if you want to wait until later. The new configuration does not take effect until
you perform the Hard Reset action.
6.
When the reset is complete, right-click the Switch component and select Attributes. In the
Configuration section, confirm that the value of the Compare State attribute is Same.
Managing One of the Star Topologies With OSM
OSM supports all topologies of a ServerNet cluster: the star topologies (
, and
and the newer layered topology.
Router Connections in a Layered Topology
Router Connections for Switch Node Ports
Port
Internal Router
Port
External Slot
0
1
1
6
1
1
2
0
2
1
7
1
2
2
0
3
1
8
1
3
2
0
4
1
9
1
4
2
Router Connections for Ports Connecting to Other Switches
Port
Internal Router
Port
External Slot
6
5
1
2
Zone
7
5
2
8
5
1
3
5
5
2
7
3
1
11
Layer
7
4
2
7
1
3
7
2
4
