IOMF2 (I/O Multifunction 2)

Each I/O multifunction 2 (IOMF2) CRU in a NonStop server contains these components:

A

service processor (SP)

Two internal

SCSI controllers

One external

SSAC

A ServerNet plug-in card (

PIC

), which provides connectivity to

internal ServerNet fabrics

Location in OSM Tree: System > Group > Module > IOMF2

Slot Location: IOMF2 CRUs are located in slots 50 and 55 of Nonstop S-series I/O enclosures
(service side).

Example: IOMF2 (1.1.55)

Attributes

IOMF2

Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK.

Values

Service State

Physical

A code that identifies the generation of the component. Hardware revision
codes are used for tracking components.

Hardware Revision

Identifies the manufacturer of the component.

Manufacturer

The part number of the component that was assigned in manufacturing. Use
part numbers for identifying and ordering parts.

Part Number

Whether the component is powered on.

Values

Power State

A unique serial number that identifies the component. Track IDs are used for
tracking components.

Track ID

Logical

The operational voltage of the IOMF2 CRU (specifically, the raw voltage
supplied to the DC-to-DC converters).

DCC Voltage

Which, if any, ServerNet router ports on this IOMF2 CRU are disabled. OSM
actions to disable or enable a ServerNet port are performed as directed by
OSM alarm repair actions.

Disabled ServerNet Ports

The current voltage of the Fan CRU.

Fan Voltage

The voltage of the Main Rail, which supplies power to the IOMF2 CRU from
its own power supply

Main Rail Voltage

The current voltage on the Main Rail of the IOMF2 CRU, measured after the
fuse.

Main Rail Voltage After Fuse

The voltage measured between the MOSFET switch and the diode to the
DCC. The MOSFET switch is located on the Other Rail between the alternate
power supply and the DCC.

MOSFET Voltage

The voltage of the Other Rail, which connects the IOMF2 CRU to the other
power supply in the enclosure (to provide power in the event of a problem
with the Main Rail power supply).

Other Rail Voltage

The current voltage on the Other Rail of the IOMF2 CRU, measured after the
fuse.

Other Rail Voltage After Fuse

168 System Resources
