Whether the switch module is installed and responding.
Values: Present, Absent, and Unknown

Presence

The track ID of the switch module midplane.

Track ID

Identifies the manufacturer of the component.

Manufacturer

The hardware revision of the switch module midplane.

Hardware Revision

Logical

A unique, read-only number stored in nonvolatile memory (SEEPROM) on a
cluster switch. The Globally Unique ID can be used programmatically to
identify the switch.

Globally Unique ID

The current value of the 4-digit numeric selector setting.
Example: 9621

Current Numeric Selector Setting

User-assigned text, that can be used to help identify the module. The text is
assigned by using the Set Locator action.
Example: Switch Group On Right in 1206

Locator

The 4-digit numeric selector setting that is currently used by the firmware.
Example: 9621

Numeric Selector Setting Used by
Firmware

Temperature

The current temperature, in degrees Celsius (°C), inside the enclosure of the
module.

Current Value

The maximum acceptable air intake temperature is 65 degrees Celsius. If
the temperature rises above 65 degrees, an alarm is generated.

Normal Maximum Value

Actions

Blink All LEDs Off

Turns off the blinking of the fault LEDs on the switch logic board, PICs, power supplies and fans.

SCF Equivalent: ALTER SWITCH, BLINK NONE

Blink All LEDs On

Causes the fault LEDs on the switch logic board, PICs, power supplies, and fans to start blinking.

SCF Equivalent: ALTER SWITCH, BLINK ALL

Connect to UPS

Starts a new Internet Explorer window and loads the default HTTP home page provided by the
UPS vendor.

Parameter: IP Address (the IP address of the UPS)

Replace

Invokes the Replace Switch Component guided procedure that helps to replace the switch module.

Responsive Test

Tests the connectivity of the switch module from the local node.

6780 Switch Module 269
