Set LED State

Turns on or off the amber LED located on the 4PSE. The current state is indicated by the

LED State

attribute.

Alarm Panel (Telco)

For Telco systems only, this object can be displayed and monitored in OSM by using the

Start

Monitoring Alarm Panel

action, located under the

Monitored Service LAN Devices

object. You can

access its browser-based configuration interface through the

Link to Web Interface

action.

Location in OSM Tree: System > Monitored Service LAN Devices > Alarm Panel

Attributes

Alarm Panel

Displayed in the Attributes tab and Attributes dialog box only if the value is something
other than OK.

Values

Service State

Physical

The state of the component as known to the operating system on the server.

Device Status

The version of the firmware running on the alarm panel.

Firmware Revision

The hardware version of the alarm panel.

Hardware Revision

The IPv4 address of the alarm panel.

IPv4 Address

Indicates whether the alarm panel has lost communication with the manager
that controls its LEDs. The possible values of this attribute are OK, Fault, and
Unknown.

LED Manager Communication State

The media access control (MAC) address of the alarm panel.

MAC Address

Indicates whether the alarm panel microprocessor is in a good state (passed
POST). The possible values of this attribute are OK, Fault, and Unknown.

Microprocessor State

The part number of the component that was assigned in manufacturing. Use
part numbers for identifying and ordering parts.

Part Number

The state of the power in input A of the alarm panel. The possible values of
this attribute are OK, Fault, and Unknown.

Power Input A State

The state of the power in input B of the alarm panel. The possible values of
this attribute are OK, Fault, and Unknown.

Power Input B State

A unique identification number assigned to each alarm panel in
manufacturing.

Serial Number

Physical Location

The values displayed by these attributes are assigned through the

Physical Configuration Tool

.

A user-defined name assigned to identify the rack in which the alarm panel
is located.

Rack Name

A number (from 1 to 42) assigned to describe the location of the alarm panel
within the rack.

Rack Offset

Alarm Panel (Telco)

87
