ME FPGA Update

Allows you to update the FPGA code file for the Maintenance Entity (ME) of the ServerNet Switch
Board.

NOTE:

Because the hard reset required to complete an FPGA update disrupts a ServerNet fabric,

you should perform a

Check Storage Dependence on ServerNet Fabric

action to make sure it is

safe before proceeding with the FPGA update. Then, update the ServerNet switch boards on a
single fabric at a time and wait at least 5 minutes after completion before checking storage
dependence and updating the switch boards on the other fabric.

ME Firmware Update

Allows you to update the firmware file for the Maintenance Entity (ME) of the ServerNet Switch
Board.

Power Cycle

Power cycles the ServerNet Switch Board.

Replace

Launches the guided procedure to replace a ServerNet switch board in an IOAM or processor
switch.

NOTE:

For an HP Integrity NonStop NS14000 or NS1000 system, the Replace action launches

a documented service procedure describing how to replace a ServerNet Switch Board unique to
that type of system.

Set LED State

Turns the ServerNet Switch Board LED on or off.

Soft Reset

Reinitializes the firmware without affecting the ServerNet Switch Board hardware or the routing
tables.

Service Processor (SP)

The service processor (SP) controls environmental and maintenance functions and acts as the master
of the serial maintenance bus (SMB). The service processor is a physical component of

IOMF2

)

CRUs.

Location in OSM Tree: System > Group > Module > IOMF2 > SP

Slot Location: Service processors are located in slots 50 and 55 of I/O enclosures (service side).

Example: SP (1.1.50)

Attributes

SP

Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK.

Values

Service State

Service Processor (SP)

217
