Switch-to-Node PIC
A plug-in card (PIC) on the 6770 switch module that connects to a ServerNet node. The last part
of the name contains the port number where the PIC is located. Only the PICs in ports 0 through
7 of the switch are used for switch-to-node connections.
Location in OSM tree: External ServerNet Fabric > Switch Group > Switch Module > Switch >
Switch PIC
Example: Switch PIC $ZZSMN.X2.4 (indicates the PIC in port 4 of switch X2)
Attributes
Switch PIC
Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK.
Values
Service State
Logical
The state of connectivity between the switch and the node to which this PIC
connects.
Values:
Connected
Not Connected
Connected to Switch With Wrong Fabric
Connected to Node
Connected to Wrong Port
Connected to Different Switch
Connected to Switch With Wrong Configuration
Unknown
Connectivity Status
Whether the PIC is installed and responding.
Values: Present, Absent, Unknown Presence
The state of the external ServerNet fabric from the local node to the remote
node connected via this port.
Values
Fabric State
Neighbor ServerNet Node
The neighbor node to which this PIC is connected.
Example: ServerNet Local Node \STAR1 Node Name
The ServerNet node number of the neighbor node to which this PIC is
connected. Node Number
Actions
Node Responsive Test
Tests the connectivity on the external ServerNet fabric through this port.
Switch Node Port
On the 6780 switch , an external transceiver port that connects to a ServerNet node.These ports
reside only on switch PICs in slots 6 through 9.
Location in OSM tree: External ServerNet Fabric > Switch Group > Switch Module > Switch PIC
> Switch Port
Example: Switch Port (1010.1.6.1)
Switch-to-Node PIC 287
