The version of the firmware running on the switch.

Firmware Revision

The IPv4 address of the switch.

IPv4 Address

Lists the port numbers of ports on the switch that have lines connected.

Lines Connected

Lists the port numbers of ports on the switch that have been disconnected
(since the OSM server has been running).

Lines Disconnected

Configurable location identifier set in the web interface (launched by the

Link

to Web Interface

action) by selecting Configuration tab > System Info >

System Location.

Location

The media access control (MAC) address of the switch.

MAC Address

Hardware model information for the ProCurve switch.

Model

The part number of the component that was assigned in manufacturing.
Not displayed for ProCurve 2510 switches; see Model attribute for switch
model details.

Part Number

The version of the startup bootcode for the switch.

ROM Version

A unique identification number assigned to each switch in manufacturing.

Serial Number

Physical Location

The values displayed by these attributes are assigned through the

Physical Configuration Tool

.

A user-defined name assigned to identify the rack in which the maintenance
switch is located.

Rack Name

A number (from 1 to 42) assigned to describe the location of the maintenance
switch within the rack.

Rack Offset

Actions

Link to Web Interface

Opens a Web interface that provides detailed device configuration and information for the
maintenance switch.

Rediscover

Causes OSM to refresh and reanalyze the object. Refresh refers to OSM updating the attribute
values displayed in the OSM Service Connection interface. Reanalyze refers to the running of
OSM incident analysis, which checks EMS event messages and creates alarms in OSM if certain
conditions exist.

Stop Monitoring

Stops OSM from monitoring the maintenance switch.

Memory Card (Blade Element)

In the OSM Service Connection, Memory Card objects are displayed as subcomponents under
the:

Blade Element

object for Integrity NonStop NS1000, NS1200, NS2000 series, NS2100,

NS2200 series, NS2300, NS2400 series, NS5000, and NS3000AC servers.

Location in OSM Tree: System > Blade Complex > Blade Element > Memory Card

Processor Blade

object for Integrity NonStop BladeSystems.

Location in OSM Tree: System > Enclosure > Processor Blade > Memory Card

Memory Card (Blade Element)

175
