NOTE:

For a SAS Disk Enclosure in a Telco system, the fans and power supplies are represented

in OSM by a pair of

SAS Power Supply and Fan

objects.

Attributes

SAS Disk Enclosure

Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK.

Values

Service State

Physical

Identifies the manufacturer of the component.

Manufacturer

The model number of the SAS disk enclosure that was assigned in
manufacturing.

Model

The serial number of the SAS disk enclosure.

Serial Number

Connected SAS Card-1

The name of one of the two

SAS cards

to which this SAS disk enclosure is

connected. The other is identified under the Connected SAS Card-2 attribute.

SAS Card

The port on the SAS card to which the SAS disk enclosure is connected.

SAS Port

Connected SAS Card-2

The name of one of the two

SAS cards

to which this SAS disk enclosure is

connected. The other is identified under the Connected SAS Card-1 attribute.

SAS Card

The port on the SAS card to which the SAS disk enclosure is connected.

SAS Port

Logical

Indicates whether the status of the SAS disk enclosure fans is Fully Redundant
or non-redundant.

Fan Status

Indicates whether the status of the SAS disk enclosure power supplies is Fully
Redundant or non-redundant.

Power Supply Status

Indicates whether the temperature of the SAS disk enclosure is normal or out
of range.

Temperature Status

Physical Location

The values displayed by these attributes are assigned through the

Physical Configuration Tool

.

A user-defined name assigned to identify the rack in which the SAS disk
enclosure is located.

Rack Name

A number (from 1 to 42) assigned to describe the location of the SAS disk
enclosure within the rack.

Rack Offset

208 System Resources
