Physical

A code that identifies the generation of the component. Hardware revision codes are
used for tracking components.

Hardware Revision

Identifies the manufacturer of the component.

Manufacturer

The part number of the component that was assigned in manufacturing. Use part numbers
for identifying and ordering parts.

Part Number

Indication of whether the component is powered on.

Values

Power State

A unique serial number that identifies the component. Track IDs are used for tracking
components.

Track ID

Logical

The configuration type of this resource.
Values: CCSA, E4SA, FESA, G4SA, GESA, TRSA, Unknown

Configured Type

The state of the component as known to the operating system on the server.

Values

Device State

Actions

Abort

Terminates operation of the Common Communication ServerNet adapter (CCSA) CRU and its
associated ServerNet addressable controller (SAC). When the Abort action finishes, the CCSA
CRU and SAC are in the Stopped state.

Start

Starts the Common Communication ServerNet adapter (CCSA) CRU and its associated ServerNet
addressable controller (SAC). The CCSA CRU and the SAC must be in the Stopped state before
you perform this action.

During startup, the controller operational code is automatically loaded into the SAC. When the
Start action completes, both the CCSA CRU and SAC are in the Started state.

Stop

Rather than automatically stopping the CCSA (as the Abort action does), this action first warns
you if the CCSA is currently in use (and stops it only after you confirm).

Test Verify

Checks the health of the Common Communication ServerNet adapter (CCSA) CRU. It determines
whether the CCSA CRU can communicate with at least one SAC on the board.

CLIM

In the OSM Service Connection, a CLIM object represents each CLuster I/O Module (CLIM)
connected to a NonStop BladeSystem or supported NonStop NS-series system. CLIMs are configured
initially in the OSM Low-Level Link, then by using the

Configure CLIM

action. CLIM software updates

– both basic CLIM software and INS software (for Telco only) – are done in the OSM Low-Level
Link.

For each CLuster I/O Module (CLIM), the OSM Service Connection displays these subcomponents,
depending on whether it is a Storage CLIM or an IP CLIM:

DIMM

Fan

CLIM 103
