Attributes

Line $ZZWAN

Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK.

Values

Service State

Logical

The name of the WAN device associated with the line.
Example: $TP6S1

If no device is configured, "FREE" is shown.

Device Name

The name of the data link control (DLC) task associated with the line.
Format: adapter name.clip number.DLC line number

Example: $ZZWAN.#D08XE5.1.DLC0

DLC Task Name

The state of the data link control (DLC) task associated with the line as known
to the operating system.
Values: Starting, Started, Stopped, Unknown, and Indeterminate (CLIP is
inaccessible).

DLC Task State

Actions

External Loopback Test

Performs the external loopback firmware diagnostic test.

Start DLC Task

Starts the data link control (DLC) task associated with the SWAN Line. When the Start action
completes, the task is in the Started State.

Stop DLC Task

Stops the data link control (DLC) task associated with the SWAN Line. When the Stop action
completes, the task is in the Stopped State. Device objects already using the task are not affected
by this action, but subsequent attempts to download tasks will fail.

SWAN Path

A subcomponent of

SWAN CLIP

s and SWAN 2 CLIPs. Every CLIP has two paths, path A and path

B. These paths represent the two Ethernet interfaces on the SWAN concentrator.

Location in OSM Tree: System > SWAN Collection > SWAN > CLIP > Path

Example: PATH $ZZWAN.#SWAN2.1.B

Attributes

PATH $ZZWAN

Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK.

Values

Service State

230 System Resources
