Switch to Primary Path

Switches processing from the backup to the primary path.

Test Verify

Runs the power-on self-test for the disk and tests the internal circuitry of the drive.

Validate Checksum

Scans the user data area of a disk for sector checksum errors. If the action fails, the Action Details
dialog box reports a sector checksum error and suggests that you spare the sector only if you
believe there is a drive media problem.

For additional information, use the OSM Event Viewer. Retrieve events using $ZLOG as the source
criteria and RAL as the subsystem criteria, and look for Disk-sector-failure events (event number
7001). In the event detail, a Sector-failure-count token shows how many sector checksum errors
were found, and a Disk-logical-sector token appears for each error, providing the logical address
of that failing sector.

You can perform the Validate Checksum action while the disk drive is in use. The action prompts
you to specify an optional process priority for the action. If not specified, the current default priority
is used.

External Disk Collection

When one or more external disks are connected to a system, an External Disk Collection object
appears in both the tree pane and the overview pane of the OSM Service Connection. In both
panes, this object displays an alarm or yellow icon if alarms or degraded conditions exist on any
of the individual external disks contained within. You can expand the External Disk Collection icon
in the tree pane (but not in the overview pane) to select and monitor individual external disks.

Location in OSM Tree: Under System

Example: External Disk Collection

Attributes

None.

Actions

None.

Fan

A component that circulates air into the enclosure to help maintain optimal temperature. Each
system enclosure contains two fans.

Location in OSM Tree: System > Group > Module > Fan

Example: Fan (1.1.22)

Attributes

Fan

Displayed in the Attributes tab and Attributes dialog box only if attention or
service is required.

Values

Service State

138

System Resources
