Battery

The battery customer-replaceable unit (CRU), located in Nonstop S-series processor or I/O
enclosures, is an assembly of 24 cells rated at 2.5 amp-hours per cell. The batteries are designed
to handle occasional power failures that might occur at typical computer sites. Each processor or
I/O enclosure contains two batteries.

Location in OSM Tree: System > Group > Module > Battery

Slot Location: In processor enclosures, battery CRUs are located in slots 23 and 28 (appearance
side).

Example: Battery (1.1.28)

Attributes

Battery

Displayed in the Attributes tab and Attributes dialog box only if the value is something
other than OK.

Values

Service State

Physical

Identifies the manufacturer of the component.

Manufacturer

Indication of whether the component is powered on.

Values

Power State

Logical

The condition of the battery CRU.

Fully Charged: The battery is fully charged.

Charging: The battery is in the process of being charged.

Critical:T he battery needs recharging or replacement.

Unknown: The battery is not responding, and its state cannot be determined.

Charge State

The initial state of the power supply CRU at the time of discovery.

Values

Enabled State

Upper Voltage Sensor

The current voltage of the upper twelve cells of the battery.

Current Value

Lower Voltage Sensor

The current voltage of the lower twelve cells of the battery.

Current Value

Differential Voltage Sensor

The current voltage difference between the upper and lower cells of the battery.

Current Value

Battery

91
