The initial state of the component at the time of discovery.
Values: OK, Fault Transceiver Device State
Whether the transceiver is enabled.
Enabled: The component is operational.
Disabled: The component is present but not operational.
Transceiver Enabled State
Neighbor Switch Port
The name of the port to which this port is connected.
Format: Port (Group.Module.Slot.Port)
where:
Group can be 1010, 1020, 1030, 1011, 1021 or 1031.
Module can be 1, 2, 3 or 4.
Slot can be 2, 3, 11, 12 or 13.
Port can be 1, 2, 3 or 4.
Switch Port
Actions
None.
UPS (6770 Switch Module)
The uninterruptible power supply (UPS) is a component of a 6770 switch module that provides
two hours of power if both the primary and backup AC power sources fail.
Location in OSM tree:External ServerNet Fabric > Switch Group > Switch Module > UPS
Example:UPS $ZZSMN.X1
Attributes
UPS
Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK.
Values
Service State
Physical
The part number of the UPS. Part Number
A unique serial number that identifies the component. Track IDs are used for
tracking components. Track ID
The VA rating (volts multiplied by amps) and the firmware version of the UPS.
Example: UPS 1440 VA FW -0039 Type
Logical
The percentage of charge remaining in the UPS batteries. Estimated Charge Remaining
The amount of time remaining (in minutes) that the UPS battery will provide
power to the switch in the event that both the primary and backup rails lose
power, or if the input voltage of the AC power source is not within the
allowable range. Remaining Time
The remaining capacity level in the UPS batteries.
Values: Normal, Low, Depleted
If the value is Depleted, the UPS is unable to sustain the present load if utility
power is lost or absent.
Remaining Capacity Status
UPS (6770 Switch Module) 291
