Logical

Whether the switch is installed and responding.
Values: Present, Absent, and Unknown

Presence

User-assigned text that can be used to help identify the switch. The text is
assigned by using the Set Locator action.
Example: Switch On Left in 1205

Locator

The network topology and ServerNet nodes supported by this 6770 switch.
The value is equivalent to the configuration tag of the ServerNet II switch.

Values

Topology

Actions

Replace

Launches an interactive procedure that provides help for replacing switch components.

Set Locator

This action allows you to enter text to aid in locating or identifying the switch. This text appears
as the Locator attribute. These ASCII characters cannot be used in the Set Locator field: =, +, &,
or %. Also, copy and paste features do not work in this field. For more information, see

Specifying

a Cluster Switch Locator String

Value: Free-form text up to 64 characters long.

Example: Switch On Left in 1205

SCF Equivalent: SCF ALTER SWITCH $ZZSMN, NEAREST { X | Y}, LOCATOR string

6780 Switch Module

A hardware component that provides connectivity for multiple nodes of a second-generation
ServerNet cluster using the layered topology. As part of the layered topology, the 6780 switch
module comprises one cluster switch layer within a cluster switch group. The 6780 switch connects
to the nodes through fiber-optic cables.

The subcomponents of the 6780 switch module are the

, and

Location in OSM tree: External ServerNet Fabric > Switch Group > Switch Module

Example: witch Module $ZZSMN.Y21 (1021.1)

[The 6780 switch module on the Y fabric of zone 2, occupying layer 1]

Attributes
