NOTE:

* SNMP Read Access Community and SNMP Write Access Community user groups and

access privileges are established by the administrator for the UPS. For information on how an
administrator configures these user groups, see the OSM Configuration Guide.

Motherboard (CLIM)

A subcomponent of G6 and Gen8

CLIMs

.

Location in OSM Tree: System > CLIMs > CLIM > Motherboard

Attributes

None.

Actions

Replace

Launches a documented service procedure to replace a CLIM motherboard.

NIC (CLIM)

A subcomponent of the

CLIM

.

For Gen8 CLIMs, there are three types of NIC cards, as identified by the Model and Part Number
attributes. The Models are:

HP Ethernet 1Gb 4-port 331FLR Adapter

HP NC560SFP+ 1GbE NIC

HP Ethernet 1Gb 2-port 332T Adapter (HP NC332T NIC)

Location in OSM Tree: System > CLIMs > CLIM > NIC

Attributes

NIC

Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK.

Values

Service State

Logical

The state of the NIC as known to the operating system on the server. Possible
values include: OK and Fault.

Device State

Physical

The model number of the CLIM NIC that was assigned in manufacturing.

Model

Displayed only for NICs on a Gen8 CLIM, this represents the part number
of the NIC assigned in manufacturing, and used for identifying and ordering
a replacement.

Part Number

Firmware

Indication of the differences, if any, between the current and default NIC
firmware versions.

Values

Compare State

The name of the file to be used for an NIC firmware update.

Default File Name

Motherboard (CLIM)

179
