Logical

The ID to which the device answers on the SCSI bus:
4 or 5: Tape devices

6 or 7: Controllers

8 and 9: SCSI extenders/FC converters

The remaining IDs are for the device on the SCSI bus.

SCSI ID

The bus to which the device is attached:
Bus 1 or 2: Internal device

Bus 3: External device

SCSI Bus Number

Actions

Responsive Test

Verifies that the component is installed and responding.

ServerNet Interface Card (Blade)

A processor switch plug-in card (PIC) used to provide internal ServerNet connections for the Blade.
In the OSM Service Connection, this object is displayed as a subcomponent of:

Blade Element

object for Integrity NonStop NS1000, NS1200, NS2000 series, NS2100,

NS2200 series, NS2300, NS2400 series, NS5000, and NS3000AC servers.

Location in OSM Tree: System > Blade Complex > Blade Element > ServerNet Interface Card

Processor Blade

object for Integrity NonStop BladeSystems.

Location in OSM Tree: System > Enclosure > Processor Blade > ServerNet Interface Card

Attributes

ServerNet Interface Card

Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK.

Values

Service State

Physical

The part number of the component that was assigned in manufacturing. Use
part numbers for identifying and ordering parts.
Displayed only for Integrity NonStop NS1000, NS1200, NS2000 series,
NS5000, and NS3000AC servers.

Part Number

Actions

Replace

Launches a documented service procedure to replace the ServerNet Interface Card in a

Processor

Blade

.

210
